JL585A - Aruba

HPE FlexFabric 5710 48SFP+ 6QSFP+ or 2QSFP28 Switch (JL585A) is a high-performance, low-latency Layer 3 data centre switch designed for top-of-rack deployments in enterprise and cloud environments. It offers a robust set of features tailored for modern networking demands.

Key Specifications

• Ports:

  • 48 × 10GbE SFP+ ports

  • 6 × 40GbE QSFP+ ports or 2 × 100GbE QSFP28 ports

• Performance:

  • Switching capacity: 1,440 Gbps

  • Forwarding rate: 1,071 Mpps

  • MAC address table: Up to 208,000 entries

• Management Interfaces:

  • 1 × 1GbE SFP management port

  • 1 × 1GbE RJ45 management port

  • 1 × Mini USB

  • 1 × Serial console

• Power & Cooling:

  • Supports redundant power supplies (options: JL589A, JL590A, JL592A, JL593A)

  • 5 fan module slots (options: JL594A, JL595A)

  • Power consumption: Approximately 74W

• Physical Characteristics:

  • Form factor: 1U rack-mountable

  • Dimensions: 1.7" (H) × 17.3" (W) × 15.7" (D)

  • Weight: Approximately 22 lbs

• Software Features:

  • Supports Layer 2 and Layer 3 protocols

  • IPv4 and IPv6 support

  • VXLAN and EVPN capabilities

  • MACsec encryption for enhanced security

  • Intelligent Resilient Framework (IRF) for simplified management and rapid convergence
